Espesor mm. Espesor pulg. Peso kg/pie2 Peso kg/m2 3' X 8' kg 3' X 10' kg 4' X 8' kg 4' X 10' kg 6' X 20' kg
Largo: pulg.
Ancho: pulg.
Largo: mm.
Ancho: mm.
1 25.400 1.000 18.524 199.390 444.575 555.719 592.767 740.958 2,222.875 0.000 0.000
7/8 22.225 0.875 16.208 174.466 389.003 486.254 518.671 648.338 1,945.015 0.000 0.000
3/4 19.050 0.750 13.893 149.543 333.431 416.789 444.575 555.719 1,667.156 0.000 0.000
5/8 15.875 0.625 11.577 124.619 277.859 347.324 370.479 463.099 1,389.297 0.000 0.000
1/2 12.700 0.500 9.262 99.695 222.287 277.859 296.383 370.479 1,111.437 0.000 0.000
7/16 11.110 0.437 8.102 87.214 194.458 243.072 259.277 324.096 972.289 0.000 0.000
3/8 9.525 0.375 6.946 74.771 166.716 208.394 222.287 277.859 833.578 0.000 0.000
5/16 7.930 0.312 5.783 62.251 138.798 173.498 185.065 231.331 693.992 0.000 0.000
1/4 6.350 0.250 4.631 49.848 111.144 138.930 148.192 185.240 555.719 0.000 0.000
3 6.070 0.239 4.427 47.650 106.243 132.804 141.657 177.072 531.215 0.000 0.000
4 5.690 0.224 4.150 44.667 99.592 124.490 132.789 165.986 497.959 0.000 0.000
5 5.310 0.209 3.873 41.684 92.941 116.176 123.921 154.901 464.703 0.000 0.000
6 4.940 0.194 3.603 38.779 86.465 108.081 115.286 144.108 432.323 0.000 0.000
3/16 4.760 0.187 3.471 37.366 83.314 104.143 111.085 138.857 416.570 0.000 0.000
7 4.550 0.179 3.318 35.718 79.638 99.548 106.185 132.731 398.192 0.000 0.000
8 4.180 0.165 3.048 32.813 73.162 91.453 97.550 121.937 365.812 0.000 0.000
9 3.800 0.150 2.771 29.830 66.511 83.139 88.682 110.852 332.556 0.000 0.000
10 3.420 0.135 2.494 26.847 59.860 74.825 79.813 99.767 299.300 0.000 0.000
1/8 3.170 0.125 2.312 24.885 55.484 69.355 73.979 92.474 277.422 0.000 0.000
11 3.040 0.120 2.217 23.864 53.209 66.511 70.945 88.682 266.045 0.000 0.000
12 2.660 0.105 1.940 20.881 46.558 58.197 62.077 77.596 232.789 0.000 0.000
13 2.280 0.090 1.663 17.898 39.907 49.883 53.209 66.511 199.534 0.000 0.000
14 1.900 0.075 1.386 14.915 33.256 41.570 44.341 55.426 166.278 0.000 0.000
15 1.710 0.067 1.247 13.424 29.930 37.413 39.907 49.883 149.650 0.000 0.000
16 1.520 0.060 1.109 11.932 26.604 33.256 35.473 44.341 133.022 0.000 0.000
17 1.370 0.054 0.999 10.755 23.979 29.974 31.972 39.965 119.895 0.000 0.000
18 1.210 0.048 0.882 9.499 21.179 26.473 28.238 35.298 105.893 0.000 0.000
19 1.060 0.042 0.773 8.321 18.553 23.191 24.738 30.922 92.766 0.000 0.000
20 0.910 0.036 0.664 7.144 15.928 19.910 21.237 26.546 79.638 0.000 0.000
21 0.840 0.033 0.613 6.594 14.702 18.378 19.603 24.504 73.512 0.000 0.000
22 0.790 0.031 0.576 6.202 13.827 17.284 18.436 23.046 69.137 0.000 0.000
23 0.680 0.027 0.496 5.338 11.902 14.878 15.869 19.837 59.510 0.000 0.000
24 0.610 0.024 0.445 4.789 10.677 13.346 14.236 17.795 53.384 0.000 0.000
25 0.530 0.021 0.387 4.161 9.277 11.596 12.369 15.461 46.383 0.000 0.000
26 0.450 0.018 0.328 3.533 7.876 9.845 10.502 13.127 39.382 0.000 0.000
27 0.420 0.017 0.306 3.297 7.351 9.189 9.802 12.252 36.756 0.000 0.000
28 0.380 0.015 0.277 2.983 6.651 8.314 8.868 11.085 33.256 0.000 0.000
29 0.340 0.013 0.248 2.669 5.951 7.439 7.935 9.918 29.755 0.000 0.000
30 0.300 0.012 0.219 2.355 5.251 6.564 7.001 8.751 26.254 0.000 0.000

Nota: el peso calculado es teórico, considerando una densidad del acero de 7.85 gr/cm3.
